B86306A0418S000

Power Line Filter Modules Overview

The B86306A0418S000 is a line filter manufactured by EPCOS - TDK Electronics, designed for high-current applications. It features a chassis mount configuration and supports a voltage rating of 520VAC with a current capacity of 418A. This component functions as an electromagnetic interference suppression device for power lines.

Power Line Filter Modules Feature Summary

• Chassis mount design for robust installation
• High current handling capability up to 418A
• Voltage rating of 520VAC

Power Line Filter Modules Applications

• Industrial power systems
• Large-scale machinery
• Power distribution units

Power Line Filter Modules Procurement Notes

Verify the specific ordering code against official TDK documentation to ensure compatibility with your system requirements. Confirm that the chassis mounting style and electrical ratings match your design specifications before procurement.

Power Line Filter Modules Selection Notes

Select this component based on its high current rating and 520VAC voltage support. Ensure the chassis mount form factor fits the available space in the equipment enclosure and meets the required electromagnetic interference suppression standards.

Power Line Filter Modules Part Context

This part belongs to the EPCOS line filter series, which provides electromagnetic interference filtering solutions. The brand operates under TDK Electronics, specializing in passive electronic components for industrial and automotive applications.

Power Line Filter Modules Replacement Considerations

Consult official TDK cross-reference lists for verified substitutes. Ensure any replacement maintains the 418A current rating and 520VAC voltage specification without altering the chassis mount interface.
