CA.25

Antennas RF Overview

The Taoglas Limited CA.25 is a dual-band surface-mount RF antenna designed for wireless connectivity applications. It operates across the 2.4GHz and 5GHz frequency ranges, specifically covering 2.4GHz to 2.5GHz and 5.15GHz to 5.85GHz. This loop-type antenna supports Wi-Fi standards and is constructed for SMT assembly processes.

Antennas RF Feature Summary

• Dual-band operation supporting both 2.4GHz and 5GHz ISM bands
• Loop antenna design optimized for compact surface-mount integration
• Compliant with RoHS directives for environmental safety

Antennas RF Applications

• Wi-Fi devices requiring dual-band connectivity
• Bluetooth-enabled consumer electronics
• IoT modules utilizing 2.4GHz or 5GHz frequencies

Antennas RF Procurement Notes

Verify the specific datasheet version and mechanical dimensions prior to procurement, as antenna performance is highly dependent on the host PCB ground plane and layout. Confirm that the dual-band specification aligns with the target regulatory requirements for the intended market. Ensure the surface-mount footprint matches the design files provided in the official documentation.

Antennas RF Selection Notes

Select this component when a low-profile, dual-band solution is required for space-constrained designs. The CA.25 is suitable for applications needing simultaneous or switched operation between 2.4GHz and 5GHz bands. Consider the mechanical height and mounting orientation relative to other components in the assembly area.

Antennas RF Part Context

Taoglas Limited specializes in antenna solutions for automotive, M2M, and IoT sectors. The CA.25 belongs to their embedded antenna portfolio, targeting compact wireless devices. As a dual-band part, it addresses the growing demand for versatile connectivity in modern electronic products without requiring multiple distinct antenna elements.
