CNY65ST

$2.34

Description：OPTOISOLTR 8.2KV 1CH TRANS 4-SMD
Series：-
Mfr：Vishay Semiconductor Opto Division
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:9d7efe160d03 Category: Transistor, Photovoltaic Output Optoisolators Brand: Vishay Semiconductor Opto Division

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

CNY65ST is listed in the Transistor, Photovoltaic Output Optoisolators range at ChipApex. The manufacturer field lists Vishay Semiconductor Opto Division. Its product description is OPTOISOLTR 8.2KV 1CH TRANS 4-SMD. Review the specifications below when checking this part for your BOM.

Transistor, Photovoltaic Output Optoisolators specifications for CNY65ST

Description：OPTOISOLTR 8.2KV 1CH TRANS 4-SMD
Series：-
Mfr：Vishay Semiconductor Opto Division
Package：Tape & Reel (TR),Cut Tape (CT)
Number of Channels：1
Voltage - Isolation：8200Vrms
Current Transfer Ratio (Min)：50% @ 5mA
Current Transfer Ratio (Max)：300% @ 5mA
Turn On / Turn Off Time (Typ)：5µs, 3µs
Rise / Fall Time (Typ)：2.4µs, 2.7µs
Input Type：DC
Output Type：Transistor
Voltage - Output (Max)：32V
Current - Output / Channel：50mA
Voltage - Forward (Vf) (Typ)：1.32V
Current - DC Forward (If) (Max)：75 mA
Vce Saturation (Max)：300mV
Operating Temperature：-55°C ~ 85°C
Mounting Type：Surface Mount
Package / Case：4-SMD, Gull Wing
Supplier Device Package：4-SMD
Grade：-
Qualification：-

Transistor, Photovoltaic Output Optoisolators datasheet and documents for CNY65ST

CNY65ST

Transistor, Photovoltaic Output Optoisolators Overview

The CNY65ST is a single-channel optocoupler featuring an NPN phototransistor output and surface-mount packaging. It provides high isolation voltage of 8200Vrms with a maximum collector-emitter voltage of 32V and continuous collector current of 50mA. The device operates within a temperature range of -55°C to 85°C, offering a current transfer ratio between 50% and 300%. Typical switching times include rise and fall durations of 2.4µs and 2.7µs respectively.

Transistor, Photovoltaic Output Optoisolators Feature Summary

Provides very high electrical isolation capability for signal transmission across potential barriers
Utilizes a standard NPN phototransistor output configuration for straightforward circuit integration
Designed for surface-mount assembly to facilitate automated PCB manufacturing processes

Transistor, Photovoltaic Output Optoisolators Applications

Industrial control systems requiring galvanic isolation
Signal coupling in measurement and testing equipment
Power supply feedback loops for safety compliance

Transistor, Photovoltaic Output Optoisolators Procurement Notes

Verify the specific suffix designation against official Vishay documentation to ensure correct performance characteristics. Confirm that the selected variant matches the required current transfer ratio and isolation voltage specifications for the intended application environment before finalizing procurement orders.

Transistor, Photovoltaic Output Optoisolators Selection Notes

Select this component when high isolation voltage is critical for system safety and reliability. Ensure the surface-mount package type aligns with available PCB footprint constraints. Verify that the operating temperature range meets the environmental requirements of the deployment location.

Transistor, Photovoltaic Output Optoisolators Part Context

This part belongs to the CNY series of optocouplers manufactured by Vishay Semiconductor Opto Division. It represents a specialized surface-mount variant designed for applications demanding robust electrical isolation in compact electronic assemblies.
