ERZ-V14D511

ERZ-V14D511 is listed in the Varistors, MOVs range at ChipApex. The manufacturer field lists Panasonic Electronic Components. Its product description is VARISTOR 510V 6KA DISC 15.5MM. Review the specifications below when checking this part for your BOM.

Varistors, MOVs specifications for ERZ-V14D511

• Description：VARISTOR 510V 6KA DISC 15.5MM
• Series：ZNR®
• Mfr：Panasonic Electronic Components
• Package：Bag
• Maximum AC Volts：320 V
• Maximum DC Volts：410 V
• Varistor Voltage (Min)：459 V
• Varistor Voltage (Typ)：510 V
• Varistor Voltage (Max)：561 V
• Current - Surge：6 kA
• Energy：190J
• Number of Circuits：1
• Capacitance @ Frequency：350 pF @ 1 kHz
• Operating Temperature：-40°C ~ 85°C (TA)
• Mounting Type：Through Hole
• Package / Case：Disc 15.5mm
• Grade：-
• Qualification：-
• Features：-

Varistors, MOVs datasheet and documents for ERZ-V14D511
