ESK227M035AG3EA

ESK227M035AG3EA is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists KEMET. Its product description is CAP ALUM RAD 85C. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for ESK227M035AG3EA

• Description：CAP ALUM RAD 85C
• Series：ESK
• Mfr：KEMET
• Package：Cut Tape (CT),Tape & Box (TB)
• Capacitance：220 µF
• Tolerance：±20%
• Voltage - Rated：35 V
• ESR (Equivalent Series Resistance)：-
• Lifetime @ Temp.：2000 Hrs @ 85°C
• Operating Temperature：-40°C ~ 85°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：290 mA @ 120 Hz
• Ripple Current @ High Frequency：348 mA @ 10 kHz
• Lead Spacing：0.138" (3.50mm)
• Size / Dimension：0.315" Dia (8.00mm)
• Height - Seated (Max)：0.492" (12.50mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can

Aluminum Electrolytic Capacitors datasheet and documents for ESK227M035AG3EA
