F-217X

$12.45

Description：PWR XFMR LAMINATED 14.4VA CHAS
Series：Single Secondary
Mfr：Triad Magnetics
Package：Box

SKU:432da54dda96 Category: Power Transformers Brand: Triad Magnetics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

F-217X is listed in the Power Transformers range at ChipApex. The manufacturer field lists Triad Magnetics. Its product description is PWR XFMR LAMINATED 14.4VA CHAS. Review the specifications below when checking this part for your BOM.

Power Transformers specifications for F-217X

Description：PWR XFMR LAMINATED 14.4VA CHAS
Series：Single Secondary
Mfr：Triad Magnetics
Package：Box
Type：Laminated Core
Voltage - Primary：115V
Voltage - Secondary (Full Load)：12V
Current - Output (Max)：1.2A
Primary Winding(s)：Single
Secondary Winding(s)：Single
Center Tap：No
Power - Max：14.4VA
Mounting Type：Chassis Mount
Termination Style：Wire Leads
Size / Dimension：82.55mm L x 41.28mm W
Height - Seated (Max)：50.80mm
Voltage - Isolation：1500Vrms
Weight：1 lb (453.59 g)

Power Transformers datasheet and documents for F-217X

F-217X

Power Transformers Overview

The Triad Magnetics F-217X is an industrial power transformer designed for chassis mounting with wire leads. It features a maximum power rating of 14.4 VA and operates at 60 Hz. The primary winding accepts 115 VAC input. The secondary output provides 12.0 V at 1.2 A. This component utilizes a laminated core construction suitable for general industrial control applications requiring reliable voltage transformation.

Power Transformers Feature Summary

Chassis mount design with integrated wire leads for straightforward installation
Laminated core construction optimized for industrial control environments
Single secondary output configuration providing stable voltage transformation

Power Transformers Applications

Industrial control panels
Equipment power supply circuits
General industrial machinery

Power Transformers Procurement Notes

Verify the specific datasheet version to confirm electrical tolerances and insulation class before integration. Ensure chassis mounting hardware compatibility with the physical dimensions. Confirm that the wire lead gauge meets the current requirements of the target circuit. Check regulatory compliance status such as RoHS for the specific production batch.

Power Transformers Selection Notes

Select this model when a 115V primary source is available and a 12V secondary output is required. The 14.4 VA rating supports loads up to 1.2 A. Consider the chassis mount style if panel space allows for external mounting rather than PCB integration. Verify that the frequency specification matches the system's 60 Hz operation.

Power Transformers Part Context

This component belongs to the F series of industrial power transformers from Triad Magnetics. The series typically offers various voltage configurations for standard line voltages. These units are generally intended for replacement or new designs in equipment requiring isolated AC power sources for downstream rectification or control logic.
