F66T3R30SE

Overview

The F66T3R30SE is a 30-degree sweep elbow fitting designed for the Hoffman Lay-In series of moisture-proof wireways. It accommodates a 6.00 x 6.00 inch internal cross-section and is constructed from steel with a gray polyester powder paint finish. The unit features top and bottom removable covers secured by quick-release latches to facilitate convenient access for wiring and cable management during installation.

Feature Summary

• Features top and bottom removable covers for easy maintenance
• Equipped with quick-release latch mechanisms for secure closure
• Designed as a 30-degree sweep elbow for continuous runs

Applications

• Moisture-proof wireway systems requiring directional changes
• Continuous cable routing in industrial environments
• Electrical installations needing protected conduit pathways

Procurement Notes

Verify that the specified application requires a 30-degree sweep configuration rather than a standard 90-degree elbow. Confirm the wireway system matches the 6.00 x 6.00 inch dimension requirement. Ensure compatibility with existing Hoffman Lay-In series components regarding latch mechanisms and cover removal procedures.

Selection Notes

Select this component when a gradual 30-degree turn is necessary within a 6x6 inch wireway network. Consider environmental conditions requiring moisture protection and the need for accessible cable management via removable covers. Validate that the steel construction and gray finish meet project specifications.

Part Context

This fitting belongs to the Hoffman Lay-In series, which specializes in moisture-proof trunking solutions. The series utilizes removable covers and quick-release hardware to simplify the installation and inspection of electrical wiring in demanding industrial settings.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
