FIN1940E.100.M

Power Line Filter Modules Overview

The Enerdoor FIN1940E.100.M is a three-phase (Wye) EMC/EMI line filter module designed for industrial applications. It features a two-stage filtering architecture with terminal block connections. The unit supports AC frequencies of 50/60 Hz and has a current rating of 100 A. It operates within a voltage range up to 500 VAC. Leakage current specifications typically fall between 3 mA and 15 mA. The device provides attenuation for both differential and common mode noise, ensuring compliance with electromagnetic compatibility standards in demanding electrical environments.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise suppression
• Terminal block connection method for secure installation
• Designed for three-phase Wye configuration systems
• Provides effective EMI/RFI attenuation for sensitive equipment

Power Line Filter Modules Applications

• Industrial automation machinery
• Medical equipment power supplies
• Renewable energy systems
• CNC machine tools

Power Line Filter Modules Procurement Notes

Verify the specific part number suffix against official Enerdoor documentation to confirm exact current ratings and terminal configurations. Ensure the application environment matches the specified voltage and frequency parameters. Confirm that the Wye configuration aligns with the existing power distribution system before procurement.

Power Line Filter Modules Selection Notes

Select this model when high-current three-phase filtering is required for Wye-connected systems. Consider the two-stage design for applications needing superior attenuation compared to single-stage units. Verify that the terminal block interface suits the available wiring infrastructure and panel space constraints.

Power Line Filter Modules Part Context

This component belongs to the Enerdoor FIN1940E series, which specializes in three-phase plus neutral filters. The series is engineered to deliver excellent attenuation and versatile EMC performance across various sectors including industrial, residential, and medical fields. These modules are part of Enerdoor's broader portfolio of electromagnetic compatibility solutions.

Power Line Filter Modules Replacement Considerations

Consult official Enerdoor substitution guides for verified equivalents. Generic cross-references may not match the specific two-stage topology or terminal block interface requirements.
