FLLE2025AQDI

Power Line Filter Modules Overview

The KEMET FLLE2025AQDI is a single-phase EMI power line filter designed for chassis mounting. It features a metal case filled with self-extinguishing resin and supports a rated current of 25 A at voltages up to 300 VAC or 300 VDC. The unit operates within a frequency range of 50/60 Hz and includes M4 threaded terminals for connection. Certified by ENEC and UR, it provides general-purpose electromagnetic interference attenuation suitable for industrial applications.

Power Line Filter Modules Feature Summary

• Single-phase EMC/EMI filtering with medium attenuation characteristics
• Chassis mount construction utilizing a metal case filled with self-extinguishing resin
• Equipped with M4 threaded terminal connections for secure installation

Power Line Filter Modules Applications

• General purpose industrial equipment requiring EMI suppression
• Medical devices requiring certified safety isolation
• Power supply input stages for AC/DC conversion systems

Power Line Filter Modules Procurement Notes

Verify the specific suffix 'AQDI' against official KEMET documentation to confirm the presence of M4 threaded terminals and chassis mount configuration. Ensure the application voltage does not exceed 300V AC or DC. Confirm that the required current rating aligns with the 25A specification. Check for any regional certification requirements such as ENEC or UR before finalizing procurement.

Power Line Filter Modules Selection Notes

Select this component when a robust, chassis-mounted solution is required for single-phase noise reduction. The metal housing offers mechanical durability compared to plastic enclosures. Consider the thermal environment, as the operating temperature range extends to 100°C. Verify space constraints for chassis mounting and ensure compatibility with M4 fastening hardware.

Power Line Filter Modules Part Context

This part belongs to the FLLE2-P series of single-phase filters from KEMET. The series is characterized by medium attenuation performance and versatile mounting options including fast-on or screw terminals. The AQDI variant specifically denotes the chassis mount configuration with threaded terminals, distinguishing it from panel mount or PCB mount alternatives in the same family.

Power Line Filter Modules Replacement Considerations

Consult official KEMET substitution guides for direct equivalents. Generic replacements may lack the specific UL or ENEC certifications held by this model. Ensure any substitute maintains the 25A current rating and 300V voltage limit while matching the physical mounting interface.
