FMBC-395B-3612

Power Line Filter Modules Overview

The FMBC-395B-3612 is a three-phase RFI filter from the Schurter FMBC NEO series, rated for 30 A and 520 V AC. It operates at 50/60 Hz with screw terminals. Key parameters include 6.8 μF capacitance, 1.9 mH inductance, and 33 mA leakage current. Dimensions are 275 x 85 x 50 mm. Operating temperature ranges from -25°C to 100°C. Resistance is 2.5 mΩ with 6.8 W power loss. Certified to UL1283.

Power Line Filter Modules Feature Summary

• Three-phase RFI filtering capability
• Screw terminal connection method
• FMBC NEO series design

Power Line Filter Modules Applications

• Industrial machinery noise suppression
• Power distribution systems
• Electrical equipment EMC compliance

Power Line Filter Modules Procurement Notes

Verify exact specifications against official datasheets before procurement. Confirm voltage ratings, current capacity, and certification requirements match application needs. Check availability through authorized distributors. Ensure proper handling and storage conditions are maintained. Validate compatibility with existing system interfaces.

Power Line Filter Modules Selection Notes

Select based on required attenuation levels and physical space constraints. Consider operating temperature range and leakage current limits. Verify mounting style and terminal type compatibility. Evaluate certification requirements for target markets. Compare performance metrics with alternative models in the FMBC series.

Power Line Filter Modules Part Context

Part of Schurter's FMBC NEO series, designed for industrial applications requiring reliable EMI suppression. The series offers various configurations for different current and voltage ratings. This specific model provides balanced performance for standard three-phase systems.

Power Line Filter Modules Replacement Considerations

FMBC-395B-3612 may be substituted with other FMBC series models offering similar electrical characteristics. Verify dimensional compatibility and terminal configuration before replacement. Consult manufacturer documentation for cross-reference information.
