GTC10SGSN-M89

$1.12

Description：CONN HEADER SMD R/A 10POS 2.54MM
Series：-
Mfr：Sullins Connector Solutions
Package：Bulk

SKU:d56f9299cb53 Category: Headers, Male Pins Brand: Sullins Connector Solutions

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

GTC10SGSN-M89 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Sullins Connector Solutions. Its product description is CONN HEADER SMD R/A 10POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for GTC10SGSN-M89

Description：CONN HEADER SMD R/A 10POS 2.54MM
Series：-
Mfr：Sullins Connector Solutions
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：10
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Surface Mount, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.318" (8.08mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.140" (3.56mm)
Contact Shape：Square
Contact Finish - Mating：Tin-Lead
Contact Finish Thickness - Mating：100.0µin (2.54µm)
Contact Finish - Post：Tin-Lead
Contact Material：Phosphor Bronze
Insulation Material：Polyamide (PA9T), Nylon 9T
Features：-
Operating Temperature：-65°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：600VDC

Headers, Male Pins datasheet and documents for GTC10SGSN-M89

GTC10SGSN-M89

Headers, Male Pins Overview

The GTC10SGSN-M89 is a male breakaway header connector manufactured by Sullins Connector Solutions. It features a single row with ten positions and a pitch of 0.100 inches (2.54mm). Designed for surface mount installation at a right angle, the connector utilizes phosphor bronze contacts with tin plating. The housing is constructed from black polyamide (PA9T) nylon rated UL94 V-0, providing an insulation height of 0.140 inches (3.56mm). It supports a maximum current rating of 3A and operates within a temperature range of -65°C to 150°C.

Headers, Male Pins Feature Summary

Right-angle surface mount design for compact board integration
Breakaway style allows for custom pin count separation
High-temperature capability up to 150°C

Headers, Male Pins Applications

Board-to-board interconnections
Cable-to-board connections
High-temperature electronic assemblies

Headers, Male Pins Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm RoHS compliance status as lead content may be present in specific variants. Ensure storage conditions maintain integrity of the tin-plated contacts and polyamide housing before assembly.

Headers, Male Pins Selection Notes

Select this model for applications requiring right-angle SMT headers with high thermal stability. Verify that the PCB footprint matches the 2.54mm pitch and 3.56mm height specifications. Consider the breakaway feature if variable pin counts are needed across a production run.

Headers, Male Pins Part Context

This component belongs to the GTC series of male breakaway headers from Sullins Connector Solutions. The series is characterized by its robust construction for demanding environments and flexible configuration options through its breakaway design, suitable for various industrial and commercial electronics.
