IAUMN10S5N016GAUMA1

Single FETs, MOSFETs Overview

The IAUMN10S5N016GAUMA1 is an OptiMOS™ 5 automotive power MOSFET featuring a single N-channel enhancement mode configuration. It provides a drain-source breakdown voltage of 100 V and a maximum on-state resistance of 1.6 mΩ at VGS=10V. The device supports a continuous chip-limited drain current of 310 A and a pulsed current of 1100 A. Total gate charge is specified at 142 nC, with turn-on delay time at 25 ns and fall time at 50 ns. Operating temperature ranges from -55 °C to +175 °C.

Single FETs, MOSFETs Feature Summary

• Optimized for automotive applications with extended qualification beyond AEC-Q101 standards
• Robust design validated through 100% avalanche testing
• Capable of withstanding MSL2 up to 260°C peak reflow temperatures

Single FETs, MOSFETs Applications

• General automotive applications

Single FETs, MOSFETs Procurement Notes

Verify the specific suffix 'AUMA1' against official Infineon documentation to confirm exact packaging or marking variations. Ensure compliance with RoHS requirements and confirm moisture sensitivity level (MSL2) handling procedures during assembly. Validate that the PG-HSOG-4-1 footprint matches the target PCB design constraints.

Single FETs, MOSFETs Selection Notes

Select this component when high current capacity and low conduction losses are required in space-constrained automotive environments. The 1.6 mΩ RDS(on) minimizes thermal generation under heavy loads. Verify system compatibility with the ±20 V gate-source voltage limits and ensure adequate heat dissipation for the 325 W power dissipation rating.

Single FETs, MOSFETs Part Context

This part belongs to the OptiMOS™ 5 family of power transistors designed specifically for demanding automotive electrical systems. It utilizes advanced trench technology to achieve superior performance metrics compared to previous generations. The device integrates robust protection features suitable for harsh automotive electrical environments.

Single FETs, MOSFETs Replacement Considerations

Consult official Infineon cross-reference lists for verified substitutes. Generic replacements may not match the specific automotive qualification or package dimensions.
