M22-2200846

Headers, Male Pins Overview

The Harwin M22-2200846 is a vertical shrouded pin header from the M22 series, designed for board-to-board connections. It features an 8-position configuration with a 2mm pitch and double row arrangement. The connector utilizes phosphor bronze contacts with gold plating for reliable signal transmission. Constructed with a nylon housing, it supports through-hole mounting on printed circuit boards. The component operates within a temperature range of -40°C to +105°C and carries UL 94 V-0 flammability ratings.

Headers, Male Pins Feature Summary

• Vertical shrouded design provides mechanical stability and alignment during mating
• Gold-plated phosphor bronze contacts ensure low contact resistance and corrosion resistance
• Nylon housing material offers high thermal stability and UL 94 V-0 flammability rating

Headers, Male Pins Applications

• High-density electronic assemblies requiring secure board-to-board interconnects
• Industrial control systems operating in extreme temperature environments
• Automotive electronics demanding robust connection reliability

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer datasheet to confirm contact plating and housing color specifications. Ensure compatibility with mating socket components regarding pitch and row configuration. Check for RoHS compliance status if required by project regulations. Confirm that the vertical orientation matches the PCB layout requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a vertical, shrouded header is required for dense circuit layouts. The 2mm pitch allows for compact board designs while maintaining adequate spacing. Consider the gold plating option for applications requiring superior conductivity and long-term durability. Ensure the through-hole mounting style aligns with the manufacturing process capabilities of the target assembly line.

Headers, Male Pins Part Context

This part belongs to the Harwin M22 series, which focuses on high-reliability connectors for demanding environments. The series offers various configurations including single and double rows with different pin counts. The M22-2200846 specifically addresses needs for vertical, shrouded headers in space-constrained applications requiring robust mechanical locking.

Headers, Male Pins Replacement Considerations

No direct public substitute part numbers are confirmed in the provided documentation. Verify cross-compatibility with other 2mm pitch shrouded headers only if electrical and mechanical parameters match exactly.
