M22-2530405

Headers, Male Pins Overview

The M22-2530405 is a single-row, right-angle header connector from the Harwin M22 series. It features a 2mm (0.079 inch) pitch and contains four positions. Designed for through-board mounting, it utilizes tin-plated contacts with a mating pin length of 3.5mm. The housing is constructed from nylon, providing electrical insulation rated at 500V. This component is classified as a female housing intended for board-to-board or cable applications.

Headers, Male Pins Feature Summary

• Single-row right-angle configuration for horizontal PCB integration
• Nylon housing material ensuring reliable electrical insulation
• Tin-plated contact surfaces for corrosion resistance

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board connections
• General electronic equipment assembly

Headers, Male Pins Procurement Notes

Verify the specific datasheet version to confirm current RoHS compliance status and material certifications. Ensure that the supplier documentation explicitly lists the part number M22-2530405 to avoid confusion with similar M22 series variants. Cross-reference the manufacturer's official obsolescence notifications to confirm active production status before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle connection is required for single-row interfaces. The 2mm pitch accommodates standard spacing requirements, while the 500V rating suits general signal and power distribution tasks. Verify that the 3.5mm mating length aligns with the corresponding plug connector specifications to ensure proper mechanical engagement.

Headers, Male Pins Part Context

This part belongs to the M22 series, which offers various configurations including vertical and right-angle headers. The M22-2530405 specifically denotes a four-position, single-row female housing. It complements other M22 components such as male plugs and shrouded connectors within the same ecosystem.

Headers, Male Pins Replacement Considerations

Consult Harwin Inc. for direct substitutes within the M22 family. Verify compatibility with mating parts having identical 2mm pitch and 3.5mm pin lengths.
