M22-5330205R

Headers, Male Pins Overview

The Harwin M22-5330205R is a surface mount pin header from the M22 series, designed for board-to-board connections. It features a single row with two positions and a 2 mm pitch spacing. The contacts utilize a right-angle termination style suitable for surface mounting. The component has a current rating of 2A and includes a contact finish thickness specification. This connector is supplied in tape and reel packaging for automated assembly processes.

Headers, Male Pins Feature Summary

• Right-angle surface mount termination for compact PCB integration
• Single row configuration with dual-position layout
• 2 mm pitch spacing for standardized board alignment

Headers, Male Pins Applications

• Board-to-board interconnects
• Surface mount electronics assembly
• Compact circuit board stacking

Headers, Male Pins Procurement Notes

Verify the exact RoHS compliance status through official manufacturer documentation prior to procurement. Confirm that the right-angle surface mount orientation matches the design requirements. Ensure the 2A current rating meets the application's electrical demands. Check for any specific handling instructions related to the tape and reel packaging format during storage and reflow soldering processes.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle connection is required for space-constrained designs. The 2 mm pitch ensures compatibility with standard footprint layouts. Consider the surface mount technology for high-volume automated production lines. Verify mechanical stability needs against the single-row structural limitations.

Headers, Male Pins Part Context

This part belongs to the Harwin M22 series, which offers various header configurations. The M22 series provides options for different row counts, pitches, and termination styles. This specific model represents a minimal position variant within the broader family of board-to-board connectors.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided data. Consult Harwin directly for equivalent components or updated series replacements if this specific right-angle configuration is unavailable.
