M50-3202745

Headers, Receptacles, Female Sockets Overview

The Harwin M50-3202745 is a dual-row female receptacle connector from the Archer M50 series. It features a 1.27 mm (0.05 in) pin-to-pin spacing and a 1.27 mm row pitch, providing a total of 54 positions. Designed for surface mount technology (SMT), it utilizes gold-plated contacts to ensure reliable signal transmission. The component operates within a temperature range of -40°C to +105°C and is RoHS compliant.

Headers, Receptacles, Female Sockets Feature Summary

• Dual-row SMT receptacle configuration with 1.27 mm spacing
• Gold-plated contacts for enhanced conductivity and corrosion resistance
• RoHS compliant construction suitable for modern manufacturing standards

Headers, Receptacles, Female Sockets Applications

• Industrial control systems requiring compact interconnects
• Medical equipment needing reliable board-to-board connections
• Automotive electronics utilizing surface mount assembly processes

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific suffix against official Harwin documentation to confirm exact contact count and plating specifications. Ensure compatibility with automated SMT placement equipment regarding height and footprint constraints. Confirm that the selected variant meets all necessary environmental certifications for the intended deployment region.

Headers, Receptacles, Female Sockets Selection Notes

Select this model when a low-profile, high-density connection is required on printed circuit boards. The 1.27 mm pitch allows for significant I/O density within limited spatial areas. Consider the SMT mounting method for streamlined assembly workflows compared to through-hole alternatives.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Archer M50 series, designed for high-reliability applications. The series offers various configurations including headers and sockets with different row counts and mounting styles. The M50-3202745 specifically addresses needs for dense, surface-mounted female connections.

Headers, Receptacles, Female Sockets Replacement Considerations

Consult Harwin's official cross-reference guides for direct substitutes. Verify that any alternative maintains identical 1.27 mm pitch, 54-position count, and SMT mounting characteristics to ensure mechanical and electrical compatibility.
