M50-4700745

Headers, Male Pins Overview

The Harwin M50-4700745 is a rectangular header connector from the ARCHER series, designed for surface mount technology. It features a dual in-line configuration with 14 positions arranged in two rows of seven. The connector utilizes a 1.27 mm pitch and includes a shrouded design to ensure proper alignment during assembly. Contact surfaces are gold-plated brass pins, rated for 1 A current and 300 V voltage. Operating temperatures range from -40°C to +105°C.

Headers, Male Pins Feature Summary

• Shrouded vertical header design for precise board-to-board alignment
• Gold-plated male pin contacts for reliable signal transmission
• Surface mount termination style optimized for automated pick-and-place processes

Headers, Male Pins Applications

• Industrial control systems requiring robust interconnects
• Automotive electronics modules
• General purpose circuit board assemblies

Headers, Male Pins Procurement Notes

Verify the specific suffix against the manufacturer's official datasheet to confirm exact physical dimensions and packaging specifications. Ensure compatibility with mating socket connectors within the same ARCHER series family. Confirm RoHS compliance status through the latest environmental declaration documents provided by Harwin Inc. prior to final procurement authorization.

Headers, Male Pins Selection Notes

Select this component when a low-profile, shrouded SMT header is required for high-density layouts. The 1.27 mm pitch allows for compact spacing compared to standard 2.54 mm options. Consider the 1 A current rating and 300 V insulation limits when designing power distribution paths on the target printed circuit board.

Headers, Male Pins Part Context

This part belongs to the Harwin ARCHER series, known for its reliability in harsh environments. The M50 prefix indicates a specific product line within the broader rectangular connector portfolio. It serves as a critical interface element in multi-layer PCB architectures where space constraints dictate the use of fine-pitch surface mount technologies.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Harwin M50 series variants with identical 14-position, 1.27 mm pitch configurations. Verify that any alternative maintains the same shrouded height and solder tail geometry to fit existing footprints without mechanical interference.
