M55-3000642R

Headers, Male Pins Overview

The Harwin M55-3000642R is a board-to-board and wire-to-board connector from the Archer Kontrol series. It features a 1.27 mm pitch with 6 positions in a single row configuration. Designed for surface mount technology, it utilizes vertical straight termination. The component supports a current rating of 1.2 A per contact and a voltage rating of 100 VAC. Housing material is polyamide (PA), and contacts are gold-plated phosphor bronze.

Headers, Male Pins Feature Summary

• Archer Kontrol series design for reliable board-to-board interconnects
• Surface mount vertical orientation for compact PCB integration
• Gold-plated phosphor bronze contacts for corrosion resistance

Headers, Male Pins Applications

• General purpose electronic assemblies
• Compact consumer electronics modules
• Industrial control interface connections

Headers, Male Pins Procurement Notes

Verify the specific suffix 'R' indicates tape and reel packaging when sourcing. Confirm RoHS compliance status through official manufacturer documentation prior to final procurement decisions. Ensure compatibility with standard SMT reflow profiles during assembly planning.

Headers, Male Pins Selection Notes

Select this part for applications requiring low-profile vertical interconnects with a 1.27 mm pitch. The single-row male header format suits space-constrained designs. Verify that the 1.2 A current rating meets circuit requirements and that polyamide housing withstands environmental conditions.

Headers, Male Pins Part Context

This component belongs to the Harwin Archer Kontrol family, known for high-density connectivity solutions. The M55 series specifically targets modern electronics needing robust, small-pitch connectors. This 6-position variant offers a balance between signal density and physical footprint for vertical mounting.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided data. Cross-reference with other Harwin M55 series variants if position count or row configuration differs.
