MGBBT-00290-P

$1.55

Description：XFMR PROP EP13 TH, ROHS C1306
Series：-
Mfr：TE Connectivity Passive Product
Package：Bulk

SKU:13cc2f87999b Category: Pulse Transformers Brand: TE Connectivity Passive Product

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MGBBT-00290-P is listed in the Pulse Transformers range at ChipApex. The manufacturer field lists TE Connectivity Passive Product. Its product description is XFMR PROP EP13 TH, ROHS C1306. Review the specifications below when checking this part for your BOM.

Pulse Transformers specifications for MGBBT-00290-P

Description：XFMR PROP EP13 TH, ROHS C1306
Series：-
Mfr：TE Connectivity Passive Product
Package：Bulk
Transformer Type：-
Inductance：6.1mH
ET (Volt-Time)：-
Turns Ratio - Primary:Secondary：-
Mounting Type：Through Hole
Size / Dimension：0.550" L x 0.550" W (13.97mm x 13.97mm)
Height - Seated (Max)：0.500" (12.70mm)
Operating Temperature：-40°C ~ 85°C
Grade：-
Qualification：-

Pulse Transformers datasheet and documents for MGBBT-00290-P

MGBBT-00290-P

Pulse Transformers Overview

The MGBBT-00290-P is a pulse transformer manufactured by TE Connectivity Passive Product, designed for through-hole mounting. It features an inductance of 6.1mH and a maximum DC resistance of 2.45 Ohms. The component has a height of 12.7 mm and is classified under Audio & Signal Transformers.

Pulse Transformers Feature Summary

Through-hole mounting configuration
Pulse transformer functionality

Pulse Transformers Applications

Audio signal processing circuits
Signal transformation applications

Pulse Transformers Procurement Notes

Verify the specific datasheet for detailed electrical characteristics and mechanical drawings before integration. Confirm that the through-hole package dimensions align with the target PCB layout. Ensure the maximum DC resistance and inductance values meet the circuit design requirements for optimal performance.

Pulse Transformers Selection Notes

Select this component when a through-hole pulse transformer with 6.1mH inductance is required. Consider the 2.45 Ohms DC resistance limit for power loss calculations. Verify compatibility with audio or signal transformer application environments.

Pulse Transformers Part Context

This part belongs to the TE Connectivity Passive Product portfolio, specifically within the Audio & Signal Transformers category. It serves as a specialized component for signal conditioning and isolation tasks requiring through-hole assembly methods.
