MTLW-103-06-F-S-125

Headers, Male Pins Overview

The MTLW-103-06-F-S-125 is a .100 inch (2.54 mm) pitch modified low profile through-hole strip header manufactured by Samtec Inc. This specific part number designates a single-row configuration with six pins. The connector features a vertical assembly orientation and utilizes a .025 inch (.635 mm) square post terminal system. It is equipped with a .125 inch post height and a total overall length of .335 inches. The contact plating specification for this variant is 10 microinches of gold flash over nickel, ensuring reliable electrical conductivity.

Headers, Male Pins Feature Summary

• Features an elastic stack design that allows the modification of post height and body position in precise increments to accommodate varying board-to-board spacing requirements.

Headers, Male Pins Applications

• Board-to-board interconnections requiring variable stacking heights
• Vertical mounting on printed circuit boards
• Low-profile electronic assemblies

Headers, Male Pins Procurement Notes

Verify the exact pin count, row configuration, and post height against the datasheet before procurement. Confirm that the specified gold flash plating meets the environmental and conductivity requirements for the target application. Ensure the through-hole termination method aligns with the manufacturing process capabilities of the assembly facility.

Headers, Male Pins Selection Notes

Select this component when a single-row, low-profile header with flexible stacking capabilities is required. The .100 inch pitch is standard for general-purpose interconnects. Consider the .125 inch post height relative to the mating connector or PCB thickness to ensure proper engagement without mechanical interference.

Headers, Male Pins Part Context

This component belongs to the MTLW series of modified low profile headers. The series is characterized by its ability to adjust to different stacking heights while maintaining a compact profile. It serves as a versatile solution for connecting multiple circuit boards in tight spaces where standard fixed-height headers would not fit.

Headers, Male Pins Replacement Considerations

Compatible mating connectors include the MTMM series headers. When substituting, verify that the replacement maintains the same .100 inch pitch, single-row layout, and compatible post dimensions to ensure mechanical and electrical compatibility.
