QBLP613-Y

LED Indication - Discrete Overview

The QBLP613-Y is a yellow light-emitting diode from the QBLP613 series by QT Brightek. It features a cool white diffused lens configuration with a rectangular shape and dome top. The component utilizes a 2-SMD, 1204 package for right-angle surface mount installation. Key electrical parameters include a typical forward voltage of 3.2V and a test current of 20mA. The device emits yellow light at a peak wavelength of 588nm with a luminous intensity of 780mcd. It offers a wide viewing angle of 120 degrees and operates within a temperature range of -40°C to 85°C.

LED Indication - Discrete Feature Summary

• Right-angle surface mount design facilitates compact PCB layout integration.
• Diffused lens structure provides uniform light distribution and reduced glare.
• Wide 120-degree viewing angle ensures broad visibility from multiple angles.

LED Indication - Discrete Applications

• Status indication in consumer electronics devices
• Panel indicators for industrial control equipment
• Signal lights in automotive interior lighting systems

LED Indication - Discrete Procurement Notes

Verify the specific suffix codes against official datasheets to confirm optical characteristics and packaging type. Ensure compatibility with standard reflow soldering profiles for SMD components. Confirm RoHS compliance status prior to procurement to meet environmental regulations. Cross-reference manufacturer part numbers with distributor listings to avoid ordering errors.

LED Indication - Discrete Selection Notes

Select this component when a right-angle LED footprint is required for space-constrained designs. The 1204 package size suits applications needing moderate luminous intensity. Consider the 3.2V forward voltage drop for power supply calculations. Verify thermal management requirements for continuous operation within the specified temperature range.

LED Indication - Discrete Part Context

This model belongs to the QBLP613 series of surface-mount LEDs. The series offers various color options including red, green, blue, and yellow variants. All members share similar physical dimensions and mounting configurations. The series targets general-purpose indicator applications requiring reliable performance.

LED Indication - Discrete Replacement Considerations

Direct substitutes may include other 1204 package LEDs with matching forward voltage and current ratings. Verify pinout orientation and lens style differences before substitution. Consult manufacturer cross-reference lists for approved equivalent parts.
