R573483685LP

RF Switches Overview

The R573483685LP is a high-frequency RF relay manufactured by Radiall USA, Inc. It operates within the Ramses SMA series and supports frequencies up to 18 GHz. The device functions as a Single Pole Triple Throw (SP3T) switch with latching capabilities. It features an auto-reset mechanism and utilizes BCD TTL diodes for control logic. The unit requires a supply voltage of 24V to 30V DC. This component is designed for demanding RF applications requiring reliable signal routing.

RF Switches Feature Summary

• Supports Single Pole Triple Throw (SP3T) switching configuration
• Operates at frequencies up to 18 GHz
• Features latching functionality with auto-reset capability
• Utilizes BCD TTL diode control logic

RF Switches Applications

• High-frequency RF signal routing
• Test and measurement equipment
• Telecommunications systems
• Aerospace and defense electronics

RF Switches Procurement Notes

Verify the exact part number suffix against official Radiall documentation to ensure correct specification alignment. Confirm availability status directly with the manufacturer or authorized distributors, as stock levels may vary. Ensure that the required supply voltage and control logic interface match your system design requirements before procurement.

RF Switches Selection Notes

Select this component when an 18 GHz SP3T switching solution is required. Consider the latching nature and auto-reset feature for power management strategies. Verify compatibility with SMA connectors and BCD TTL control signals. Evaluate thermal performance and environmental ratings if operating in harsh conditions.

RF Switches Part Context

This part belongs to the Ramses SMA series from Radiall, specialized for high-frequency applications. The series is known for robust performance in RF environments. The LP suffix likely denotes specific packaging or variant details; consult datasheets for precise identification. It complements Radiall's portfolio of interconnect components for critical infrastructure.

RF Switches Replacement Considerations

Consult Radiall technical support for direct substitutes. Verify electrical parameters such as insertion loss, isolation, and switching speed. Ensure mechanical compatibility with existing SMA interfaces. Check control logic voltage levels and pinout configurations for equivalent parts.
