S4EB-L-3V

S4EB-L-3V is listed in the Power Relays, Over 2 Amps range at ChipApex. The manufacturer field lists Panasonic Electric Works. Its product description is RELAY GEN PURPOSE 4PST 4A 3V. Review the specifications below when checking this part for your BOM.

Power Relays, Over 2 Amps specifications for S4EB-L-3V

• Description：RELAY GEN PURPOSE 4PST 4A 3V
• Series：S
• Mfr：Panasonic Electric Works
• Package：Tube
• Mounting Type：Through Hole
• Coil Voltage：3VDC
• Contact Form：4PST-NO (4 Form A)
• Contact Rating (Current)：4:00 AM
• Switching Voltage：250VAC, 48VDC - Max
• Load - Max Switching：1000VA, 192W
• Coil Current：66.7 mA
• Coil Type：Latching, Single Coil
• Features：-
• Termination Style：PC Pin
• Seal Rating：Sealed - Fully
• Coil Insulation：-
• Must Operate Voltage：2.1 VDC
• Must Release Voltage：-
• Operating Temperature：-55°C ~ 65°C
• Contact Material：Silver Alloy, Cadmium Free
• Approval Agency：CSA, UR
• Relay Type：General Purpose
• Grade：-
• Qualification：-
• Operate Time：15 ms
• Release Time：15 ms

Power Relays, Over 2 Amps datasheet and documents for S4EB-L-3V
