SL 11 214 22 Z

Headers, Male Pins Overview

The SL 11 214 22 Z is a one-row male pin header connector from Fischer Elektronik. It features a 0.635 mm pitch and contains 22 positions. The component utilizes through-hole mounting for PCB integration. Contact materials consist of copper alloy with tin plating to ensure reliable electrical conductivity. The insulating body is constructed from polyamide (PA46), providing structural stability and thermal resistance. This connector is designed for secure mating with corresponding socket interfaces in electronic assemblies.

Headers, Male Pins Feature Summary

• One-row male pin configuration for standard board-to-board or cable connections
• Precision 0.635 mm pitch ensures accurate alignment during assembly
• Through-hole termination method provides robust mechanical fixation
• Tin-plated copper contacts offer corrosion resistance and stable signal transmission

Headers, Male Pins Applications

• General-purpose electronic circuit interconnections
• PCB module stacking applications
• Test and measurement equipment connectors
• Industrial control system wiring harnesses

Headers, Male Pins Procurement Notes

Verify the exact part number against official Fischer Elektronik documentation to confirm contact count and pitch specifications. Ensure compatibility with mating socket components regarding height and terminal geometry. Check for RoHS compliance status if required by specific project regulations. Confirm package quantity matches procurement requirements before finalizing orders.

Headers, Male Pins Selection Notes

Select this component when a single-row male header with 0.635 mm spacing is required. Consider the through-hole mounting style for applications needing high mechanical strength. Evaluate the operating temperature range against environmental conditions. Compare physical dimensions with available PCB space constraints to ensure proper fitment within the design layout.

Headers, Male Pins Part Context

This part belongs to the SL 11 series of precision connectors manufactured by Fischer Elektronik GmbH & Co. KG. The series focuses on reliable interconnection solutions for electronic systems. Components in this line are engineered for consistent performance in various industrial and commercial applications. The manufacturer emphasizes quality standards and material durability for long-term operational reliability.

Headers, Male Pins Replacement Considerations

Consult official distributor databases for direct substitutes matching the 0.635 mm pitch and 22-position configuration. Verify that alternative headers maintain identical mounting style and contact material properties. Ensure dimensional compatibility with existing PCB footprints and mating connectors before implementation.
