SL 12 SMD 109 35 Z B SM

Headers, Male Pins Overview

The SL 12 SMD 109 35 Z B SM is a surface-mount male header manufactured by Fischer Elektronik. It features a 2.54 mm pitch and contains 35 contacts. The contact material is CuSn-alloy with tin-plated surfaces, while the contact sleeve utilizes Ni+≥0.2µm Au plating. Termination is achieved via soldering. The component employs a push-pull fastening type. Mating contact length measures 0.429 inches (10.90mm), and post contact length is 0.205 inches (5.20mm).

Headers, Male Pins Feature Summary

• Surface-mount technology construction for automated PCB assembly.
• Push-pull fastening mechanism for secure connection retention.
• Gold-plated contact sleeves ensuring reliable signal transmission.

Headers, Male Pins Applications

• Precision-engineered electronic component assemblies.
• Surface-mount technology applications requiring high-density connections.
• Industrial control systems utilizing board-to-board interfaces.

Headers, Male Pins Procurement Notes

Verify the complete part number including all suffixes to ensure correct contact count and plating specifications. Confirm surface mount compatibility with your specific PCB footprint requirements. Check datasheet details for mating connector dimensions to guarantee mechanical fit. Ensure storage conditions maintain integrity of tin and gold plating prior to installation.

Headers, Male Pins Selection Notes

Select this component when a 35-position surface-mount header is required. The 2.54 mm pitch aligns with standard industry spacing. Verify that the push-pull fastening style meets system retention needs. Consider the tin-plated contact surface for general purpose applications versus gold-plated sleeves for corrosion resistance.

Headers, Male Pins Part Context

This part belongs to the SL 12 SMD 109 series of male headers from Fischer Elektronik. The series offers various contact counts ranging from low to high density options. All variants share the same 2.54 mm pitch and surface-mount design philosophy. The specific model denotes the 35-contact configuration within this standardized product family.

Headers, Male Pins Replacement Considerations

Consult official Fischer Elektronik documentation for direct substitute part numbers within the SL 12 SMD 109 series. Verify identical pitch, contact count, and mounting type before substitution. Generic equivalents may not match the specific push-pull fastening or plating specifications.
