SL 15 SMD 182 23 G

Headers, Male Pins Overview

The SL 15 SMD 182 23 G is a male pin header connector from Fischer Elektronik, designed for surface mount technology applications. It features a 23-position configuration with a standard 0.100 inch (2.54 mm) pitch. The insulating body is constructed from PA 4.6 GF material, ensuring robust mechanical stability and thermal resistance. This component supports a test voltage of 2000 V and operates within a temperature range of -40°C to +163°C, with short-term tolerance up to 260°C for 10 seconds. It meets UL 94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Surface mount design for automated PCB assembly
• High dielectric strength with 2000 V test voltage rating
• Thermally stable PA 4.6 GF insulating body
• Compliant with UL 94 V-0 flammability classification

Headers, Male Pins Applications

• Stacked printed circuit board interconnections
• Complex electronic assemblies requiring reliable signal routing
• Industrial control systems with high thermal demands

Headers, Male Pins Procurement Notes

Verify the specific suffix 'G' against official Fischer Elektronik documentation to confirm plating specifications and contact material properties. Ensure compatibility with surface mount reflow profiles by checking the maximum peak temperature limits defined in the datasheet. Confirm that the 23-position count matches the target PCB footprint requirements before ordering.

Headers, Male Pins Selection Notes

Select this component when surface mount mounting is required for a 23-pin interface. The 2.54 mm pitch is standard for general-purpose interconnects. Consider the PA 4.6 GF material for environments requiring higher thermal endurance compared to standard nylon variants. Verify that the 2000 V test voltage meets the insulation requirements of the target circuit application.

Headers, Male Pins Part Context

This part belongs to the SL 15 SMD 182 series of male headers from Fischer Elektronik. The series offers various position counts and configurations for surface mount applications. The '23' indicates the specific number of contacts, while 'G' denotes the finish or variant. These connectors are engineered for precision interconnections in dense electronic layouts.

Headers, Male Pins Replacement Considerations

Cross-reference with other SL 15 SMD 182 variants if different position counts are needed. Verify that substitute parts maintain the same 2.54 mm pitch and surface mount footprint. Check that alternative manufacturers offer comparable thermal ratings and UL 94 V-0 compliance for equivalent performance.
