SL 16 SMD 182 10 S

Headers, Male Pins Overview

The SL 16 SMD 182 10 S is a male pin header connector manufactured by Fischer Elektronik, designed for surface mount installation on printed circuit boards. This component features a single row with 10 positions and utilizes a 0.100-inch (2.54 mm) pitch spacing between contacts. The connector is engineered for reliable interconnections within stacked PCB assemblies, offering high precision in its construction. It serves as a critical interface element in electronic systems requiring secure board-to-board or wire-to-board connections.

Headers, Male Pins Feature Summary

• Surface mount technology implementation for automated PCB assembly processes
• High-precision design ensuring stable mechanical and electrical performance in stacked configurations
• Single row configuration optimized for compact layout requirements

Headers, Male Pins Applications

• Stacked printed circuit board assemblies
• Board-to-board interconnection systems
• Wire-to-board connection interfaces

Headers, Male Pins Procurement Notes

Verify the specific part number SL 16 SMD 182 10 S against official Fischer Elektronik documentation to confirm surface mount compatibility and contact count. Ensure that the ordering suffix matches the required termination type and insulation characteristics. Cross-reference manufacturer datasheets for precise dimensional tolerances and thermal handling specifications before procurement.

Headers, Male Pins Selection Notes

Select this component when surface mount mounting is required for single-row headers with ten contacts. Confirm that the 2.54 mm pitch aligns with the target PCB footprint and mating connector specifications. Evaluate the insulator length and overall height constraints to ensure proper fit within the stacked PCB assembly structure without mechanical interference.

Headers, Male Pins Part Context

This model belongs to the SL 16 SMD series of male pin headers from Fischer Elektronik. The series is characterized by components designed for interconnections of stacked PCBs, where the total length allows for variable insulator options. These connectors are part of a broader family of PCB connectors focused on male headers for precise electronic integration.

Headers, Male Pins Replacement Considerations

Consult official Fischer Elektronik substitution guides for compatible alternatives. Verify that any substitute maintains the same 10-position count, 2.54 mm pitch, and surface mount form factor. Ensure mechanical dimensions and electrical ratings match the original design requirements.
