STM32F745VEH6TR

Microcontrollers Overview

The STM32F745VEH6TR is a high-performance microcontroller based on the Arm Cortex-M7 core, operating at up to 216 MHz. It features 512 Kbytes of Flash memory and 320 Kbytes of SRAM, including TCM RAM for critical real-time data. The device includes an ART Accelerator and L1 cache for zero-wait-state execution. Connectivity options encompass Ethernet, USB OTG, CANbus, I²C, SPI, UART/USART, SAI, SPDIF-Rx, IrDA, LINbus, EBI/EMI, and SD interfaces. Peripherals include three 12-bit ADCs, two 12-bit DACs, multiple timers, DMA, I²S, and a true random number generator. It operates within a voltage range of 1.7 V to 3.6 V and supports temperatures from -40°C to 85°C in a 100-pin UFBGA package.

Microcontrollers Feature Summary

• High-performance Arm Cortex-M7 core with single-precision floating-point unit (SFPU) and DSP instructions
• Adaptive Real-Time (ART) Accelerator with L1 cache enabling zero-wait-state execution from embedded flash
• Flexible external memory controller supporting SDRAM, PSRAM, NOR/NAND, and LCD parallel interface
• Integrated Chrom-ART Accelerator (DMA2D) for hardware-accelerated graphics content creation

Microcontrollers Applications

• Industrial applications requiring motor control and advanced communication interfaces
• Medical devices utilizing high-speed analog-to-digital conversion and precision timing
• Consumer electronics featuring LCD-TFT displays and audio processing via SAI/I2S
• Smart metering and grid distribution systems with secure code protection mechanisms

Microcontrollers Procurement Notes

Verify the complete part number against official STMicroelectronics documentation to ensure correct package type, temperature range, and tape-and-reel configuration. Confirm that the specific suffix matches the required manufacturing lot and quality standards. Cross-reference with the latest datasheet revision to validate peripheral availability and electrical characteristics before finalizing procurement specifications.

Microcontrollers Selection Notes

Select this component when application requirements demand high computational throughput with deterministic real-time performance. The inclusion of dedicated Data TCM RAM ensures critical routines execute without bus contention. Consider the extensive connectivity suite if system integration requires simultaneous Ethernet, USB, and industrial bus protocols. Ensure design compatibility with the 1.7 V to 3.6 V supply range and thermal constraints of the UFBGA package.

Microcontrollers Part Context

This device belongs to the STM32F745xx series, which shares architectural similarities with the STM32F746xx family. Both series utilize the Cortex-M7 core but differ in memory capacity and pin count configurations. The STM32F745xx series provides a balanced combination of processing power and peripheral richness, targeting cost-sensitive high-performance applications compared to the larger STM32F767xx or STM32F777xx variants.

Microcontrollers Replacement Considerations

Official substitutes within the same family include STM32F745VG and STM32F745VI, which offer identical core functionality but differ in package size and pin count. Verify pin compatibility and memory mapping before substitution. Other series like STM32F407 lack the Cortex-M7 architecture and associated performance enhancements.
