SUW102412C

SUW102412C is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Cosel USA, Inc.. Its product description is DC DC CONVERTER +/-12V 24V 11W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for SUW102412C

• Description：DC DC CONVERTER +/-12V 24V 11W
• Series：SUW (10W)
• Mfr：Cosel USA, Inc.
• Package：Box
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：18V
• Voltage - Input (Max)：36V
• Voltage - Output 1：12V
• Voltage - Output 2：-12V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：450mA, 450mA
• Power (Watts)：11 W
• Voltage - Isolation：500 V
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 85°C (With Derating)
• Efficiency：86%
• Mounting Type：Through Hole
• Package / Case：7-DIP Module
• Size / Dimension：1.54" L x 0.83" W x 0.26" H (39.2mm x 21.0mm x 6.5mm)
• Supplier Device Package：-

DC DC Converters datasheet and documents for SUW102412C
