SX5V20.000B10080F20TNNS

Oscillators Overview

The SX5V20.000B10080F20TNNS is a Voltage Controlled Crystal Oscillator (VCXO) manufactured by Shenzhen SCTF Electronics. It operates at a nominal frequency of 20.0000 MHz and utilizes CMOS output logic levels. The component is designed for operation with a supply voltage of 3.3V. It features an absolute pull range of ±50ppm and a frequency stability of ±30ppm. The device is housed in a compact 6-SMD, no-lead package and includes enable/disable functionality for power management control.

Oscillators Feature Summary

• Voltage controlled crystal oscillator architecture providing precise frequency generation
• CMOS output interface compatible with standard digital logic circuits
• Integrated enable and disable control pin for active power management
• Compact surface-mount packaging suitable for space-constrained designs

Oscillators Applications

• Clock signal generation in communication equipment
• Frequency synthesis systems requiring voltage tuning
• Digital circuit timing references
• Embedded systems with low power requirements

Oscillators Procurement Notes

Verify the specific ordering suffix to ensure compatibility with required frequency tolerance and load conditions. Confirm that the 3.3V supply voltage aligns with the target system design. Check the enable/disable pin configuration against the schematic requirements. Ensure the 6-SMD package footprint matches the PCB layout specifications before finalizing procurement orders.

Oscillators Selection Notes

Select this component when a stable 20 MHz reference with voltage control capability is required. The CMOS output simplifies interfacing with microcontrollers or FPGA inputs. Consider the ±50ppm pull range for applications needing frequency adjustment. The low supply current and enable feature make it suitable for battery-operated or energy-efficient portable devices.

Oscillators Part Context

This VCXO belongs to the series of precision oscillators designed for high-reliability electronic applications. Shenzhen SCTF Electronics specializes in timing components that meet strict industry standards for stability and performance. The SX5V model line offers various frequency options and package types to support diverse design needs in consumer and industrial electronics.
