T820167504DH

$116.84

Description：SCR PHASE CTRL MOD 1600V 750A
Series：-

SKU:a56760e4913b Category: SCRs - Modules Brand: Powerex Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：SCR PHASE CTRL MOD 1600V 750A
Series：-
Mfr：Powerex Inc.
Package：Bulk
Structure：Single
Number of SCRs, Diodes：1 SCR
Voltage - Off State：1.6 kV
Current - On State (It (AV)) (Max)：750 A
Current - On State (It (RMS)) (Max)：1175 A
Current - Non Rep. Surge 50, 60Hz (Itsm)：10950A, 12000A
Operating Temperature：-40°C ~ 125°C (TJ)
Mounting Type：Clamp On
Package / Case：TO-200AC, B-PUK
Voltage - Gate Trigger (Vgt) (Max)：3 V
Current - Gate Trigger (Igt) (Max)：150 mA
Current - Hold (Ih) (Max)：-
Grade：-
Qualification：-

Download product information

T820167504DH

Overview

The Powerex T820167504DH is a Phase Control Silicon Controlled Rectifier (SCR) with a 750 Amperes average on-state current and a 1600 Volts repetitive peak reverse blocking voltage. It features a typical turn-off time of 200 microseconds and requires a gate trigger current of 150 mA. The device utilizes an all-diffused, Press-Pak hermetic Pow-R-Disc construction with an amplifying gate structure.

Feature Summary

Hermetic ceramic packaging for reliable operation in harsh environments
High di/dt and dv/dt capability for robust phase control performance
Low on-state voltage to minimize conduction losses
Excellent surge and I²t ratings for high fault current tolerance

Applications

Power Supplies
Motor Control

Procurement Notes

Verify the complete 12-digit part number against official Powerex documentation to ensure correct voltage and current ratings. Confirm mounting force requirements and thermal interface specifications before integration. Check for any specific handling instructions related to the hermetic ceramic package and stud mount configuration.

Selection Notes

Select this component for applications requiring high average current and high voltage blocking capabilities in phase control circuits. Ensure the operating junction temperature remains within the specified -40 to +125 °C range. Verify that the circuit's di/dt and dv/dt stresses do not exceed the device's critical rates of rise.

Part Context

This SCR belongs to the T820 series, designed for high-power industrial applications. The series offers various voltage ratings from 200V to 2400V while maintaining a consistent 750A average current rating. The T820167504DH specifically provides a 1600V rating suitable for medium-to-high voltage AC power control systems.

Replacement Considerations

Consult official Powerex documentation for direct substitutes within the T820 family or equivalent high-current SCR models. Verify pinout compatibility and thermal resistance values when considering alternative manufacturers' components.
