TDU 1-1212

TDU 1-1212 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Traco Power. Its product description is 1W DIP-8 ISOLATED DC/DC CONVERTE. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for TDU 1-1212

• Description：1W DIP-8 ISOLATED DC/DC CONVERTE
• Series：TDU 1 (1W)
• Mfr：Traco Power
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：10.8V
• Voltage - Input (Max)：13.2V
• Voltage - Output 1：12V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：84mA
• Power (Watts)：1.008 W
• Voltage - Isolation：1.8 kV
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 85°C
• Efficiency：81%
• Mounting Type：Through Hole
• Package / Case：7-DIP Module, 4 Leads
• Size / Dimension：0.50" L x 0.40" W x 0.31" H (12.7mm x 10.2mm x 7.9mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for TDU 1-1212
