TE0710-02-35-2IF

Microcontrollers, Microprocessor, FPGA Modules Overview

The TE0710-02-35-2IF is a System on Module (SOM) from Trenz Electronic GmbH, designed for programmable logic applications. It integrates the AMD Artix-7 XC7A35T FPGA, operating at a maximum frequency of 100 MHz. The module includes 512 MB of DDR3 memory and features dual 100 MBit Ethernet PHY capabilities. Constructed in a compact 4 x 5 cm form factor, it supports industrial temperature ranges and complies with CE and UKCA standards, providing a robust solution for embedded systems requiring high-density I/O and connectivity.

Microcontrollers, Microprocessor, FPGA Modules Feature Summary

• Integrates AMD Artix-7 XC7A35T FPGA for flexible programmable logic implementation
• Includes 512 MB DDR3 memory for efficient data processing and storage
• Features dual fast Ethernet PHY for reliable network communication
• Compact 4 x 5 cm design suitable for space-constrained embedded applications

Microcontrollers, Microprocessor, FPGA Modules Applications

• Industrial automation control systems
• Embedded networking equipment
• Portable diagnostic devices
• Custom IoT gateway modules

Microcontrollers, Microprocessor, FPGA Modules Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm specific revision levels and packaging details prior to order placement. Ensure compliance with regional regulatory requirements such as CE and UKCA markings. Check for end-of-life status or alternative part recommendations if long-term supply stability is required. Validate technical specifications against current project needs before finalizing procurement.

Microcontrollers, Microprocessor, FPGA Modules Selection Notes

Select this module when a balance between FPGA flexibility and integrated memory/ethernet is needed. Consider the 100 MHz speed grade for moderate performance requirements. Evaluate the 4x5 cm footprint against board layout constraints. Compare against higher-capacity Artix-7 variants if additional logic resources are anticipated. Ensure thermal management solutions align with the module's operational temperature range.

Microcontrollers, Microprocessor, FPGA Modules Part Context

This module belongs to the Trenz Electronic TE0710 series, which focuses on AMD/Xilinx Artix-7 based System on Modules. The series offers various configurations differing by FPGA capacity, memory size, and peripheral interfaces. The TE0710-02-35-2IF specifically targets applications requiring moderate logic density with built-in networking capabilities, serving as a building block for custom embedded designs within the broader Trenz Electronic ecosystem.

Microcontrollers, Microprocessor, FPGA Modules Replacement Considerations

Public confirmed substitute part numbers include TE0710-02-35-2CF and TE0710-02-100-2IF. Verify compatibility regarding pinout, voltage levels, and software support before substitution. Note that different suffixes may indicate variations in temperature grade or package type. Consult official documentation for detailed cross-reference information.
