TLH-010-0.50-G-D-A-K

TLH-010-0.50-G-D-A-K is listed in the Arrays, Edge Type, Mezzanine (Board To Board) range at ChipApex. The manufacturer field lists Samtec Inc.. Its product description is 0.50 MM MICRO BLADE & BEAM ULTRA. Review the specifications below when checking this part for your BOM.

Arrays, Edge Type, Mezzanine (Board To Board) specifications for TLH-010-0.50-G-D-A-K

• Description：0.50 MM MICRO BLADE & BEAM ULTRA
• Series：TLH
• Mfr：Samtec Inc.
• Package：Tape & Reel (TR),Cut Tape (CT)
• Connector Type：Header, Center Strip Contacts
• Number of Positions：20
• Pitch：0.020" (0.50mm)
• Number of Rows：2
• Mounting Type：Surface Mount
• Features：Board Guide, Pick and Place
• Contact Finish：Gold
• Contact Finish Thickness：10.0µin (0.25µm)
• Mated Stacking Heights：2mm
• Height Above Board：0.056" (1.42mm)

Arrays, Edge Type, Mezzanine (Board To Board) datasheet and documents for TLH-010-0.50-G-D-A-K
