TPS62823DLCR

Voltage Regulators - DC DC Switching Regulators Overview

The TPS62823DLCR is a synchronous step-down DC-to-DC converter from Texas Instruments, designed for high-efficiency power management in compact applications. It features an adjustable output voltage range starting from 0.6 V up to 4 V, delivering a continuous output current of 3 A. The device operates with an input voltage range of 2.4 V to 5.5 V and supports a switching frequency of 2.2 MHz. Packaged in an 8-VSON-HR (2x1.5) surface-mount housing, it ensures reliable performance across a junction temperature range of -40°C to +125°C.

Voltage Regulators - DC DC Switching Regulators Feature Summary

• Synchronous buck topology provides high efficiency across the load current range
• Adjustable output voltage allows flexibility for various digital core requirements
• Compact 8-pin VSON-HR package minimizes solution footprint
• Integrated shutdown mode reduces quiescent current consumption

Voltage Regulators - DC DC Switching Regulators Applications

• Portable consumer electronics powered by single-cell lithium-ion batteries
• Embedded systems requiring efficient voltage regulation for microprocessors
• Industrial control modules with limited board space constraints
• IoT devices needing low-power standby operation capabilities

Voltage Regulators - DC DC Switching Regulators Procurement Notes

Verify the specific suffix 'DLCR' against the manufacturer's official datasheet to confirm the reel packaging configuration and tape-and-reel specifications. Ensure that the ordering documentation explicitly references the TPS62823 family parameters, as variations in suffixes may indicate different thermal or handling characteristics. Cross-reference the component marking with the official identification guide to prevent counterfeit risks during acquisition.

Voltage Regulators - DC DC Switching Regulators Selection Notes

Select this component when a 3 A output current capability is required within a small form factor. The 2.2 MHz switching frequency enables the use of smaller external inductors and capacitors compared to lower-frequency alternatives. Consider the 2.4 V minimum input voltage constraint to ensure compatibility with battery discharge profiles. The adjustable output feature simplifies design adaptation for different logic voltage levels without changing the base IC.

Voltage Regulators - DC DC Switching Regulators Part Context

This part belongs to the TPS6282x series of synchronous step-down converters, which are optimized for space-constrained portable applications. The series shares common architectural features such as high efficiency and compact packaging. The TPS62823 variant specifically distinguishes itself by offering a higher 3 A output current capacity compared to lower-current siblings in the same family, making it suitable for more demanding processing loads.

Voltage Regulators - DC DC Switching Regulators Replacement Considerations

Direct substitutes include other members of the TPS6282x family, such as the TPS62821 or TPS62822, if lower output current ratings are acceptable. For equivalent performance, verify that alternative parts support the same 3 A current rating and 2.2 MHz switching frequency. Ensure that any replacement maintains compatibility with the 8-VSON-HR package dimensions to preserve PCB layout integrity.
