TSM-113-03-S-DV-A

Headers, Male Pins Overview

The TSM-113-03-S-DV-A is a surface mount header strip manufactured by Samtec. It features a 2.54 mm (0.100 inch) pitch with two rows of contacts, providing a total of 26 positions. The connector utilizes gold-plated phosphor bronze pins designed for reliable signal transmission. This component is part of the TSM series, characterized by its low-profile design and compatibility with standard PCB assembly processes. It is intended for board-to-board or cable applications requiring secure surface mounting.

Headers, Male Pins Feature Summary

• Surface mount terminal strip configuration
• Gold-plated contact finish for corrosion resistance
• Low-profile design suitable for space-constrained layouts

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board connections
• General purpose electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to ensure correct termination style and row configuration. Confirm that the selected variant matches the required pin count and pitch specifications for the target application. Cross-reference the manufacturer datasheet to validate material properties and environmental ratings before final procurement decisions are made.

Headers, Male Pins Selection Notes

Select this component when a surface mount header with a 0.100-inch pitch is required. Ensure the mating connector aligns with the specified contact length and insulation height. Consider the thermal requirements of the soldering process relative to the liquid crystal polymer insulator rating. Verify availability of compatible mating parts for system integration.

Headers, Male Pins Part Context

This part belongs to the TSM series of flexible stacking solutions from Samtec. These headers are designed for high-density applications where vertical space is limited. The series offers various configurations including different post heights and termination styles to accommodate diverse mechanical and electrical design constraints in modern electronics.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Samtec TSM series headers with matching 2.54mm pitch and 26-position double row configuration. Verify identical surface mount termination and contact plating specifications to maintain electrical performance and mechanical fit.
