VSAB0530-R82M

Fixed Inductors Overview

The VSAB0530-R82M is a shielded molded power inductor from the CODACA VSAB series, designed for automotive applications. It features an inductance of 0.82 µH with a ±20% tolerance and a saturation current (Isat) of 8.5 A. The component has a maximum DC resistance (DCR) of 9.8 mΩ and operates at a test frequency of 100 kHz. Packaged in a 2-SMD form factor with dimensions of 5.45mm x 5.25mm x 3.10mm, it meets AEC-Q200 standards and functions reliably within a temperature range of -55°C to 155°C.

Fixed Inductors Feature Summary

• Automotive-grade reliability certified under AEC-Q200 standards
• High saturation current capability of 8.5 A for power handling
• Shielded molded construction minimizes electromagnetic interference

Fixed Inductors Applications

• Automotive power supply circuits
• On-board charger systems
• DC-DC converter modules

Fixed Inductors Procurement Notes

Verify that the specific part number suffix matches the required automotive grade specifications. Confirm that the supplier provides documentation proving compliance with AEC-Q200 standards. Ensure the ordering quantity aligns with the manufacturer's standard packaging requirements. Check for any specific storage or handling instructions related to moisture sensitivity levels before assembly.

Fixed Inductors Selection Notes

Select this component when high saturation current and automotive certification are critical. Compare the 0.82 µH value against circuit requirements to ensure proper filtering. Consider the low DCR for efficiency optimization in power paths. Evaluate the physical footprint compatibility with the target PCB layout constraints.

Fixed Inductors Part Context

This model belongs to the VSAB series of molding power chokes manufactured by Shenzhen Codaca Electronic Co., Ltd. The series is characterized by its robust construction suitable for demanding environments. The VSAB designation indicates automotive qualification, distinguishing it from standard industrial variants within the broader product portfolio.

Fixed Inductors Replacement Considerations

Direct substitutes must match the 0.82 µH inductance, 8.5 A saturation current, and 9.8 mΩ DCR specifications. Verify that alternative components also hold AEC-Q200 certification for automotive use. Ensure the replacement fits the same 2-SMD package dimensions.
