Edgeboard Connectors

Card edge or edgeboard connectors are a style of connector system in which (typically) a pattern of exposed copper regions at the periphery of a printed circuit board constitutes one-half of a mating connector pair. A common use case being the connection of accessory cards such as graphics accelerators to computer motherboards in desktop PC applications, they offer a relatively low-cost, high density interconnect option for applications where durability is not a primary concern.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
306-006-525-102 $4.68	EDAC Inc.	CONN EDGE DUAL FMALE 12POS 0.156	Bulk		Through Hole	306	-40°C ~ 105°C
306-007-400-101 $5.70	EDAC Inc.	CONN EDGE DUAL FMALE 14POS 0.156	Bulk		Free Hanging (In-Line)	306	-40°C ~ 105°C
306-007-400-102 $5.70	EDAC Inc.	CONN EDGE DUAL FMALE 14POS 0.156	Bulk		Panel Mount	306	-40°C ~ 105°C
306-007-400-103 $7.56	EDAC Inc.	CONN EDGE DUAL FMALE 14POS 0.156	Bulk		Panel Mount	306	-40°C ~ 105°C
306-007-400-104 $5.70	EDAC Inc.	CONN EDGE DUAL FMALE 14POS 0.156	Bulk		Panel Mount	306	-40°C ~ 105°C
306-007-400-107 $7.56	EDAC Inc.	CONN EDGE DUAL FMALE 14POS 0.156	Bulk		Panel Mount	306	-40°C ~ 105°C
306-007-400-108 $7.56	EDAC Inc.	CONN EDGE DUAL FMALE 14POS 0.156	Bulk		Panel Mount	306	-40°C ~ 105°C
306-007-400-112 $6.87	EDAC Inc.	CONN EDGE DUAL FMALE 14POS 0.156	Bulk		Panel Mount	306	-40°C ~ 105°C
