Edgeboard Connectors

Card edge or edgeboard connectors are a style of connector system in which (typically) a pattern of exposed copper regions at the periphery of a printed circuit board constitutes one-half of a mating connector pair. A common use case being the connection of accessory cards such as graphics accelerators to computer motherboards in desktop PC applications, they offer a relatively low-cost, high density interconnect option for applications where durability is not a primary concern.

Screen Default Ranking Price By Date

Select products	Mfr	Description	Package	Supplier Device Package	Mounting Type	Series	Operating Temperature
306-013-500-158 $9.98	EDAC Inc.	CONN EDGE DUAL FMALE 26POS 0.156	Box		Panel Mount	306	-40°C ~ 105°C
306-013-500-168 $9.98	EDAC Inc.	CONN EDGE DUAL FMALE 26POS 0.156	Box		Panel Mount	306	-40°C ~ 105°C
306-013-500-178 $9.98	EDAC Inc.	CONN EDGE DUAL FMALE 26POS 0.156	Box		Panel Mount	306	-40°C ~ 105°C
306-013-520-101 $7.52	EDAC Inc.	CONN EDGE DUAL FMALE 26POS 0.156	Box		Through Hole	306	-40°C ~ 105°C
306-013-520-102 $7.52	EDAC Inc.	CONN EDGE DUAL FMALE 26POS 0.156	Box		Panel Mount, Through Hole	306	-40°C ~ 105°C
306-013-520-103 $9.34	EDAC Inc.	CONN EDGE DUAL FMALE 26POS 0.156	Box		Panel Mount, Through Hole	306	-40°C ~ 105°C
306-013-520-104 $7.52	EDAC Inc.	CONN EDGE DUAL FMALE 26POS 0.156	Box		Panel Mount, Through Hole	306	-40°C ~ 105°C
306-013-520-107 $9.34	EDAC Inc.	CONN EDGE DUAL FMALE 26POS 0.156	Box		Panel Mount, Through Hole	306	-40°C ~ 105°C
