22152066

Headers, Receptacles, Female Sockets Overview

The Molex 22152066 is a vertical PCB header featuring a 6.35mm pitch and two circuits. Constructed with phosphor bronze contacts and nylon 6/6 resin, it utilizes tin plating for reliable termination. Designed for through-hole mounting, this component supports a maximum current of 13.5A per contact and operates within a temperature range of -55°C to +105°C. It offers full shrouding and polarization to ensure correct mating orientation.

Headers, Receptacles, Female Sockets Feature Summary

• Vertical orientation design for board-to-board or wire-to-board power connections
• Fully shrouded housing with polarization features for secure mating alignment
• Through-hole termination using tin-plated phosphor bronze contacts

Headers, Receptacles, Female Sockets Applications

• Power distribution in electronic assemblies
• Wire-to-board interconnects requiring high current capacity
• Board-to-board power delivery systems

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific part number against official Molex documentation to confirm active status and compliance details. Ensure that the required current rating and operating temperature range align with your system's thermal and electrical specifications before procurement. Cross-reference certification data such as UL recognition and RoHS compliance directly with the manufacturer's latest datasheet to guarantee regulatory adherence for your target market.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a vertical, shrouded header with a 6.35mm pitch is required for power applications. The through-hole termination method provides robust mechanical stability compared to surface mount alternatives. Consider the 13.5A current rating and -55°C to +105°C operating range to ensure compatibility with your environmental conditions and electrical load requirements.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Molex MLX series, designed for power solutions. It serves as a connector header offering vertical entry angles suitable for various power delivery configurations. The series emphasizes reliability through polarized and shrouded designs, ensuring consistent performance in demanding industrial and commercial electronics environments.

Headers, Receptacles, Female Sockets Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
