395-026-523-607

Edgeboard Connectors Overview

The EDAC Inc. 395-026-523-607 is a single-row card edge connector designed for through-hole mounting. It features 26 female positions with a 0.100-inch (2.54mm) pitch. The contacts are made of copper alloy with gold plating, housed in a black thermoplastic polyester insulator. This receptacle supports board thicknesses ranging from 0.054 to 0.070 inches and operates within a temperature range of -40°C to 105°C.

Edgeboard Connectors Feature Summary

• Single-edge female contact configuration for non-specified card applications
• Gold-plated copper alloy contacts ensure reliable signal transmission
• Thermoplastic polyester insulation provides structural stability
• Through-hole termination facilitates secure PCB integration

Edgeboard Connectors Applications

• Industrial control system interconnections
• Telecommunications equipment backplanes
• Consumer electronics module interfaces
• Automotive electronic circuit boards

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against official EDAC documentation to confirm exact pin count, termination style, and plating specifications. Ensure compatibility with target PCB stack-up dimensions and mating card thickness requirements before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this component when a single-row, 26-position interface is required for vertical panel or board-to-board connections. Confirm that the 0.100-inch pitch aligns with existing design constraints and that the operating temperature range meets environmental demands.

Edgeboard Connectors Part Context

This part belongs to the EDAC 395 series of standard card edge connectors. The series offers various position counts and termination options, providing modular solutions for diverse electronic assembly needs while maintaining consistent mechanical and electrical performance standards across the product line.

Edgeboard Connectors Replacement Considerations

Consult official EDAC substitution guides for verified cross-references. Generic equivalents may lack precise dimensional tolerances or material certifications required for critical applications.
