672D477F012DM5D

672D477F012DM5D is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Vishay Sprague. Its product description is CAP ALUM 470UF 12V RADIAL TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for 672D477F012DM5D

• Description：CAP ALUM 470UF 12V RADIAL TH
• Series：672D
• Mfr：Vishay Sprague
• Package：Bulk
• Capacitance：470 µF
• Tolerance：-10%, +50%
• Voltage - Rated：12 V
• ESR (Equivalent Series Resistance)：310mOhm @ 120Hz
• Lifetime @ Temp.：-
• Operating Temperature：-55°C ~ 105°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：945 mA @ 120 Hz
• Ripple Current @ High Frequency：1.35 A @ 100 kHz
• Lead Spacing：0.197" (5.00mm)
• Size / Dimension：0.492" Dia (12.50mm)
• Height - Seated (Max)：1.161" (29.50mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can
• Impedance：120 mOhms

Aluminum Electrolytic Capacitors datasheet and documents for 672D477F012DM5D
