77313-402-26LF

$0.81

Description：CONN HEADER VERT 26POS 2.54MM
Series：BERGSTIK®
Mfr：Amphenol ICC (FCI)
Package：Bag

SKU:e6ab1afc1777 Category: Headers, Male Pins Brand: Amphenol ICC (FCI)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

77313-402-26LF is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Amphenol ICC (FCI). Its product description is CONN HEADER VERT 26POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 77313-402-26LF

Description：CONN HEADER VERT 26POS 2.54MM
Series：BERGSTIK®
Mfr：Amphenol ICC (FCI)
Package：Bag
Connector Type：Header, Breakaway
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：26
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.230" (5.84mm)
Contact Length - Post：0.135" (3.43mm)
Overall Contact Length：0.465" (11.81mm)
Insulation Height：0.100" (2.54mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：78.7µin (2.00µm)
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Thermoplastic
Features：-
Operating Temperature：-65°C ~ 130°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for 77313-402-26LF

77313-402-26LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) 77313-402-26LF is a BergStik series unshrouded header connector designed for board-to-board and cable applications. It features a 26-position, 2-row configuration with a 2.54mm pitch. The component utilizes male pin contacts made of phosphor bronze, terminated via through-hole soldering. Contact plating includes gold or GXT on the mating interface and tin on the tail. Rated for 3A per contact, it operates within a temperature range of -65°C to 130°C. The housing is black thermoplastic with UL94 V-0 flammability rating.
