AP0603B-RNL-002MA

$0.06

Description：LED RED 0603 SMD
Series：-
Mfr：Solidlite
Package：Strip

SKU:83fcbe2c8b6e Category: LED Indication - Discrete Brand: Solidlite

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LED RED 0603 SMD
Series：-
Mfr：Solidlite
Package：Strip
Color：Red
Configuration：-
Lens Color：-
Lens Transparency：-
Millicandela Rating：15mcd
Lens Style：Rectangle with Flat Top
Lens Size：1.00mm x 0.80mm
Voltage - Forward (Vf) (Typ)：1.8V
Current - Test：2mA
Viewing Angle：130°
Mounting Type：Surface Mount
Wavelength - Dominant：625nm
Wavelength - Peak：-
Features：-
Package / Case：0603 (1608 Metric)
Supplier Device Package：603
Size / Dimension：1.60mm L x 0.80mm W
Height (Max)：0.50mm
Grade：-
Qualification：-

Download product information

AP0603B-RNL-002MA

Overview

The AP0603B-RNL-002MA is a discrete red LED from Solidlite, designed for surface-mount applications. It features a 0603 (1608 Metric) package with dimensions of 1.6mm x 0.8mm x 0.4mm. The component emits light at a wavelength of 615nm to 630nm and operates with a forward current of 2mA. The typical forward voltage range is specified as 7V to 23V.

Feature Summary

Compact 0603 surface-mount form factor suitable for space-constrained designs
Red light emission within the 615nm to 630nm spectrum
Low current operation optimized for indicator applications

Applications

LED status indicators
Panel illumination
Discrete signal indication

Procurement Notes

Verify the specific datasheet version provided by the manufacturer or authorized distributor to confirm electrical characteristics. Ensure the ordering suffix matches the required binning and packaging specifications. Cross-reference the part number with official Solidlite documentation to validate authenticity and technical compliance before procurement.

Selection Notes

Select this component for applications requiring a low-profile red indicator in a 0603 footprint. Consider the 2mA operating current and the specific wavelength range when designing optical systems. Verify that the voltage requirements align with the circuit design constraints.

Part Context

This part belongs to the Solidlite AP0603B series of surface-mount LEDs. The series offers various color options and current ratings within the same compact package, allowing for consistent mechanical design across different product lines while varying only the optical properties.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Consult official Solidlite documentation or authorized distributors for verified cross-reference data.
