CFSA69383P1-30NF

Antennas RF Overview

The TE Connectivity CFSA69383P1-30NF is a flat panel RF antenna designed for indoor applications. It operates across three frequency bands: 698MHz to 960MHz, 1.35GHz to 1.55GHz, and 1.69GHz to 3.8GHz. The unit features a maximum gain of 5.8dBi and supports a maximum power of 50W. It utilizes an N-type female connector for interface and is engineered for panel mounting with a maximum height of 7.60mm.

Antennas RF Feature Summary

• Supports GSM, LTE, and WiMax protocols
• Flat panel design for low-profile installation
• N-type female connector interface

Antennas RF Applications

• GSM networks
• LTE networks
• WiMax systems

Antennas RF Procurement Notes

Verify the specific suffix '1' in the part number to confirm the inclusion of mounting holes, as this distinguishes it from other variants in the series. Ensure compatibility with N-type connectors and validate that the specified frequency ranges align with the target network requirements before finalizing procurement.

Antennas RF Selection Notes

Select this model when a low-profile indoor solution is required for multi-band cellular and WiMax deployments. The flat panel form factor facilitates discreet integration into building infrastructure. Confirm that the N-type female interface matches existing cabling and that the 50W power rating meets system specifications.

Antennas RF Part Context

This component belongs to the CFSA series of ultra-low-profile antennas manufactured by TE Connectivity. These antennas are specifically engineered for indoor use, offering a compact profile suitable for environments where space constraints or aesthetic considerations are primary factors in antenna selection.

Antennas RF Replacement Considerations

CFSA69383P-30NF shares similar core specifications but lacks the specific mounting hole configuration indicated by the '1' suffix in the current model.
