ELRB451VSN241MA59M

ELRB451VSN241MA59M is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Chemi-Con. Its product description is CAP ALUM 450V POLAR. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for ELRB451VSN241MA59M

• Description：CAP ALUM 450V POLAR
• Series：LRB
• Mfr：Chemi-Con
• Package：Bulk
• Capacitance：240 µF
• Tolerance：±20%
• Voltage - Rated：450 V
• ESR (Equivalent Series Resistance)：-
• Lifetime @ Temp.：5000 Hrs @ 105°C
• Operating Temperature：-40°C ~ 105°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：2.2176 A @ 120 Hz
• Ripple Current @ High Frequency：6.72 A @ 100 kHz
• Lead Spacing：0.394" (10.00mm)
• Size / Dimension：1.378" Dia (35.00mm)
• Height - Seated (Max)：2.421" (61.50mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can - Snap-In
• Impedance：-

Aluminum Electrolytic Capacitors datasheet and documents for ELRB451VSN241MA59M
