IP3319CX6,135

$0.43

Description：CMC 2LN SMD ESD
Series：-
Mfr：Nexperia USA Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:74898796bd10 Category: Common Mode Chokes Brand: Nexperia USA Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

IP3319CX6,135 is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists Nexperia USA Inc.. Its product description is CMC 2LN SMD ESD. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for IP3319CX6,135

Description：CMC 2LN SMD ESD
Series：-
Mfr：Nexperia USA Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
Filter Type：Signal Line
Number of Lines：2
Current Rating (Max)：-
DC Resistance (DCR) (Max)：6Ohm (Typ)
Voltage Rating - DC：-
Voltage Rating - AC：-
Operating Temperature：-40°C ~ 85°C
Ratings：-
Approval Agency：-
Features：TVS Diode ESD Protection
Mounting Type：Surface Mount
Size / Dimension：0.053" L x 0.037" W (1.34mm x 0.95mm)
Height (Max)：0.024" (0.60mm)
Package / Case：6-UFBGA, WLCSP
Inductance @ Frequency：-
Impedance @ Frequency：-

Common Mode Chokes datasheet and documents for IP3319CX6,135

IP3319CX6,135

Common Mode Chokes Overview

The IP3319CX6,135 is an EMI filter circuit designed for dual USB 2.0 interfaces, integrating common mode chokes with electrostatic discharge (ESD) protection. Manufactured by Nexperia, this component utilizes a 6-UFBGA, WLCSP package with dimensions of 1.34 mm in length, 0.95 mm in width, and a maximum height of 0.60 mm. It operates within a temperature range of -40°C to +85°C and features a capacitance of 1.5 pF with a voltage rating of 5.5 V.

Common Mode Chokes Feature Summary

Integrates EMI filtering and bidirectional ESD protection for differential signal lines
Compact wafer-level chip scale packaging suitable for space-constrained designs
Optimized for high-speed data transmission integrity

Common Mode Chokes Applications

Dual USB 2.0 port protection
Mobile device interface circuits
Portable electronics data lines

Common Mode Chokes Procurement Notes

Verify availability status as supply may be limited or subject to factory special orders. Confirm minimum order quantities and reel specifications with authorized distributors. Ensure the ordering suffix matches the required tape and reel configuration for surface mount assembly processes.

Common Mode Chokes Selection Notes

Select this component when simultaneous EMI suppression and ESD protection are required for dual-channel USB applications. The low parasitic capacitance supports high-speed data integrity. Verify that the operating temperature range and voltage ratings align with the specific system requirements.

Common Mode Chokes Part Context

This part belongs to Nexperia's portfolio of signal conditioning and protection devices. It falls under the category of EMI/RFI filters and LC networks. The manufacturer specializes in standard and logic semiconductors, providing components for consumer, industrial, and automotive markets.

Common Mode Chokes Replacement Considerations

Consult official Nexperia documentation for qualified substitute part numbers. Ensure replacement components match the pinout, package dimensions, and electrical characteristics of the original design.
