JANTX2N2907AUA

Single Bipolar Transistors Overview

The JANTX2N2907AUA is a PNP silicon small-signal bipolar junction transistor manufactured by Microchip Technology. It features a maximum collector-emitter voltage of 60 V and a continuous collector current rating of 600 mA. The device is designed for surface-mount applications in the UA package, with a power dissipation capability of 1.8 W. It operates within a temperature range of -65°C to +200°C.

Single Bipolar Transistors Feature Summary

• High-temperature operation capability up to 200°C junction temperature
• Surface-mount construction in the UA package format
• Military-grade reliability under JANTX quality standards

Single Bipolar Transistors Applications

• Harsh environment switching circuits
• High-temperature amplifier stages
• Military aerospace signal processing

Single Bipolar Transistors Procurement Notes

Verify the specific datasheet revision and manufacturing origin when sourcing this component. Confirm that the JANTX designation aligns with required military specifications. Ensure the UA package footprint matches the design layout. Check for any export control restrictions applicable to military-grade semiconductors before finalizing procurement.

Single Bipolar Transistors Selection Notes

Select this component for designs requiring robust performance at elevated temperatures. The 600 mA current rating supports moderate load switching. Verify thermal management strategies to maintain junction temperatures within the specified 200°C limit during operation.

Single Bipolar Transistors Part Context

This part belongs to the 2N2907 family of PNP transistors. It shares electrical characteristics with commercial variants but adheres to stricter military screening and reliability standards. The JANTX suffix indicates enhanced testing beyond standard JAN requirements.

Single Bipolar Transistors Replacement Considerations

Direct replacements include other JANTX2N2907AUA units from authorized distributors. Cross-referencing with JAN2N2907AUA requires verification of parameter margins.
