KTB1100EYAA-TE

$4.92

Description：IC REG FLYBACK ADJ 1.5A 16SOIC
Series：-
Mfr：Kinetic Technologies
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:70455b9e32dc Category: Voltage Regulators - DC DC Switching Regulators Brand: Kinetic Technologies

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

KTB1100EYAA-TE is listed in the Voltage Regulators - DC DC Switching Regulators range at ChipApex. The manufacturer field lists Kinetic Technologies. Its product description is IC REG FLYBACK ADJ 1.5A 16SOIC. Review the specifications below when checking this part for your BOM.

Voltage Regulators - DC DC Switching Regulators specifications for KTB1100EYAA-TE

Description：IC REG FLYBACK ADJ 1.5A 16SOIC
Series：-
Mfr：Kinetic Technologies
Package：Tape & Reel (TR),Cut Tape (CT)
Function：Step-Up/Step-Down
Output Configuration：Positive
Topology：Flyback
Output Type：Adjustable
Number of Outputs：1
Voltage - Input (Min)：7V
Voltage - Input (Max)：100V
Voltage - Output (Min/Fixed)：3V
Voltage - Output (Max)：48V
Current - Output：1.5A
Frequency - Switching：100kHz ~ 1MHz
Synchronous Rectifier：Yes
Operating Temperature：-40°C ~ 125°C (TJ)
Mounting Type：Surface Mount
Package / Case：16-SOIC (0.295", 7.50mm Width)
Supplier Device Package：16-SOIC
Grade：-
Qualification：-

Voltage Regulators - DC DC Switching Regulators datasheet and documents for KTB1100EYAA-TE

KTB1100EYAA-TE

Voltage Regulators - DC DC Switching Regulators Overview

The KTB1100EYAA-TE is a 15W flyback switching voltage regulator IC manufactured by Kinetic Technologies. It integrates a digital isolator for feedback, supporting an input voltage range of 7V to 100V and delivering up to 1.5A output current at a maximum of 48V. The device operates with synchronous rectification and features an adjustable positive output starting from 3V. It utilizes a 16-SOIC package (0.295" width) and supports switching frequencies between 100kHz and 1MHz.

Voltage Regulators - DC DC Switching Regulators Feature Summary

Integrates a digital isolator within the feedback loop for enhanced signal isolation.
Employs synchronous rectification to improve conversion efficiency.
Supports wide input voltage ranges suitable for diverse power sources.

Voltage Regulators - DC DC Switching Regulators Applications

Isolated DC/DC converter implementations
Flyback switching regulator circuits
Signal isolation devices

Voltage Regulators - DC DC Switching Regulators Procurement Notes

Verify the specific ordering suffix against official Kinetic Technologies documentation to ensure correct pinout and functional configuration. Confirm that the 16-SOIC package dimensions match your PCB footprint requirements. Cross-reference the datasheet revision date to ensure compatibility with your design specifications before finalizing procurement orders.

Voltage Regulators - DC DC Switching Regulators Selection Notes

Select this component when a compact solution combining flyback regulation with integrated digital isolation is required. The 1.5A current capability and wide input range make it suitable for applications needing robust isolated power delivery. Ensure the thermal performance of the 16-SOIC package aligns with your system's heat dissipation constraints.

Voltage Regulators - DC DC Switching Regulators Part Context

This part belongs to Kinetic Technologies' line of switching voltage regulators designed for high-efficiency power conversion. The series emphasizes integration by combining power stage control with isolation technology, reducing the need for external discrete components in isolated power supply designs.
