M22-2040505

Headers, Male Pins Overview

The M22-2040505 is a pin header connector from the Harwin M22 series, designed for board-to-board applications. It features a 10-position configuration arranged in a dual inline (DIL) format with two rows of five contacts each. The connector utilizes a 2mm pitch and incorporates gold-plated phosphor bronze male pins. Designed for through-hole mounting, it offers a right-angle orientation to facilitate compact circuit board layouts.

Headers, Male Pins Feature Summary

• Dual inline structure provides high-density connectivity within a compact footprint
• Gold plating on contact surfaces ensures reliable signal transmission and corrosion resistance
• Right-angle design enables efficient spatial arrangement on printed circuit boards

Headers, Male Pins Applications

• Board-to-board interconnections requiring robust mechanical stability
• High-density electronic assemblies utilizing limited vertical space
• Industrial control systems demanding reliable signal integrity

Headers, Male Pins Procurement Notes

Verify component authenticity by checking manufacturer markings against official datasheets. Confirm that the part number matches the specific ten-position dual row configuration. Ensure compatibility with mating connectors regarding pitch and housing dimensions. Validate material specifications such as insulation type and contact plating thickness if required for environmental conditions.

Headers, Male Pins Selection Notes

Select this component when a right-angle, dual-row header is necessary for dense board stacking. The 2mm pitch allows for moderate pin counts without excessive width. Consider the through-hole mounting requirement and ensure PCB drill patterns align with the specified pin spacing. Evaluate thermal and electrical ratings against system operational demands.

Headers, Male Pins Part Context

This connector belongs to the M22 series, which is characterized by its push-pull locking mechanism and high reliability. The series is widely used in industrial and automotive sectors where secure connections are critical. The M22-2040505 specifically represents a standard variant within this family, offering a balance between density and ease of assembly.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 2mm pitch, 10-position DIL layout, and right-angle orientation. Verify that alternative parts maintain identical contact plating and insulation material properties. Ensure mechanical dimensions, particularly height and pin length, are compatible with existing PCB constraints and mating components.
